ELECTRO MAGNETIC BRAKE- TYPE: EBR.

SIZE

80

100

125

150

190

230

290

Torque ( N m

7

14

28

55

110

220

440

Max Speed (R P M)

7500

6500

5500

4500

4500

3000

2000

Input Power W at 20*c

12

16

20

26

36

46

60

Ø A h 8

80

100

125

150

190

230

290

Ø B h 8

63

80

100

125

160

200

250

Ø c

72

90

112

137

175

215

270

Ø D

46

60

76

95

120

158

210

Ø E H 8

35

42

52

62

80

100

125

Ø F

28

33

43

50

66

84

106

Ø G

6.3

8

10.5

12

15

18

22

Ø G 1

3 x 3.1

3 x 4.1

3 x 5.1

3 x 6.1

3 x 8.2

3 x 10.2

4 x 12.2

Ø H

4 x 4.5

4 x 5.5

4 x 6.6

4 x 6.6

4 x 9

4 x 9

4 x 11

Ø 1

3 x 5.5

3 x 7

3 x 9

3 x 10

3 x 13

3 x 16

4 x 20

K

22

24.5

27.9

31

35

41.4

47.9

K 1

37

52.9

61

73

89.4

102.9

K 2

25.5

28.5

32.9

37

42

50.4

58.9

L

18

20

22

24

26

30

35

m

2

2.5

3

3.5

4

5

6

m 1

3.5

4.3

5

5.5

6

7

8

N

15

20

25

30

38

48

55

p

1.6

1.8

2.4

2.8

3.2

4

4.3

a

0.2

0.2

0.2

0.3

0.3

0.5

0.5

b

5

6

6

10

10

15

20

Max Bore Ø S 3 H 7

17

20

30

35

40

60

80
